0.56 Single Digit 7 Segment LED Display

Description The 7-segment display, also written as “seven segment display”, consists of seven LEDs (hence its name) arranged in a rectangular fashion as shown. Each of the seven LEDs is called a segment because when illuminated the segment forms part of a numerical digit (both Decimal and Hex) to be displayed. An additional 8th LED is sometimes used within the same package thus allowing the indication of a Decimal Point,(DP). Application of 7 Segment Led Display Common Anode: Numeric Display. Hexadecimal digit Display. Low Level Display. DIY projects requiring Numeric display.
