GIGABYTE UD1600PM PG5 AI TOP 1600W 80 Plus Platinum

GIGABYTE UD1600PM PG5 AI TOP 1600w Spec – Model GP-UD1600PM PG5 Type Intel Form Factor ATX 12V v3.1 PFC Active PFC (>0.9 typical) Input Voltage 100-240 Vac (full range) Input Current 15-7.5A Input Frequency 60-50 Hz Output Capacity 1600W Dimension 150 x 190 x 86 mm Fan Type 140mm Double Ball Bearing Fan 80 PLUS Certification Platinum Efficiency 92% at typical load MTBF >100,000 hours Protection OVP/OPP/SCP/UVP/OCP/OTP Power Good Signal 100-150 ms Hold Up Time >16 ms Cable Type Flat, All black Connectors – ATX/MB 20 4 Pin x 1: 610mm – CPU/EPS 4 4 Pin x 2: 650mm – PCI-E 16 Pin x 2: 700mm – PCI-E 16 Pin to PCI-E 8 Pin x 2: 700mm – PCI-E 6 2 Pin x 8: 650mm 150mm (x4 sets) – SATA x 16: 650mm 150mm 150mm 150mm (x4 sets) – 4 Pin Peripheral x 6 4 Pin Floppy x 2: 600mm 150mm 150mm (x2 sets)
