Belden 1685ANH Cat-6A F/FTP LSZH Cable 305m/Roll

Specification:BrandBELDENPart No1685ANHOriginUSASuitable Applications"Horizontal and building backbone cable; Support current and future Category 6a and 6 applications, such as: 10GBase-T (10 Gigabit Ethernet), 1000Base-T (Gigabit Ethernet),100 Base-T, 10 Base-T, FDDI, ATMHorizontal and building backbone cable;Support current and future Category 6a and 6 applications, such as:10GBase-T (10 Gigabit Ethernet), 1000Base-T (Gigabit Ethernet),100 Base-T, 10 Base-T, FDDI, ATM" AWG23StrandingSolidTotal Number of Conductors8Material (Conductor)BC - Bare CopperNo. of Pairs4Material (Insulation)Foamed PolyethyleneIndividual Pair Shield MaterialAluminum Foil – Polyester TapeIndividual Pair Shield Coverage100%Outer Shield TypeTapeOuter Shield MaterialAluminum Foil – Polyester TapeOuter Shield Coverage100%Outer Shield Drain Wire MaterialTC – Tinned CopperOuter Shield Drain Wire SizeSolid 26 AWGOuter Jacket MaterialLSZH – Low Smoke Zero HalogenOuter Jacket RipcordYesOverall Nominal Diameter7.3 mmOperating Temperature Range- 20℃ To 75℃Max. Recommended Pulling Tension110 NMin. Bend Radius (Install)59 mmIEC SpecificationIEC 61156-5Flame TestIEC 60332-1
