Belden 7834A (008A1000) Cat 6 23 AWG solid UTP Cable 305m/ Box - Grey

Specification:BrandBELDENPart No7834A 008A1000OriginUSASuitable ApplicationsPremise Horizontal Cable, Gigabit Ethernet, 100BaseTX, 100BaseVG ANYLAN, 155ATM, 622ATM, NTSC/PAL Component or Composite Video, AES/EBU, Digital Video, RS-422, 250MHz Category 6 and PoE application. PHYSICALAWG23StrandingSolidMaterial (Conductor)BC - Bare CopperNo. of Pairs4Material (Insulation)PE - PolyethyleneMaterial (Outer Jacket)PVC - Polyvinyl ChlorideNominal Diameter1.01 mmMax. Conductor DCR93.8 Ohm/kmMax DCR Unbalanced Between Pairs [%]5%Max. Capacitance Unbalance330 pF/100mNominal Diameter6.2 mmNom.Mutual Capacitance56 pF/mMax. Mutual Capacitance56 pF/mNominal Characteristic Impedance100 OhmFrequency [MHz]100 MHzMax. Delay538 ns/100mMax. Delay Skew45 ns/100mNominal Velocity of Propagation (VP)70%Operating Temperature Range-20°C To 75°CInstallation Temp Rating0°C to 60°CISO/IEC ComplianceISO/IEC 11801-1, IEC 61156-5NEC/(UL) ComplianceCMANSI ComplianceANSI/TIA 568.2-D (2018)IEEE CompliancePoE: IEEE 802.3bt Type 1, Type 2, Type 3, Type 4
